800-3-2-3000-2Â NOSHOKÂ |Â 800 Series 0 to 3,000 Electronic Indicating Pressure Transmitters/Switch
Manufacturer:Â NOSHOK
Manufacturer Model #:Â 800-3-2-3000-2
- Compound and standard ranges from 0 psig to 10 psig through 0 psig to 7,500 psig
- 316L Stainless Steel wetted parts
- Current and voltage outputs available
- Accuracy:Â <= 0.5% of spanAccuracy for Transmitter Parameter:Â <= 0.5% of span including non-linearity, hysteresis, zero offset and end value deviation (corresponds to measured error per IEC 61298-2)Adjustment:Â Freely scalable within the range of 5:1Ambient Temperature Range:Â -20 to 80Application:Â Hydraulics & pneumaticsPower generationPumps & compressorsStamping & forming pressesWater & wastewaterCategory:Â 800 Series Electronic Indicating Pressure Transmitters/SwitchesCompensated Temperature Range:Â 0 to 80Connection Material:Â 316 Stainless SteelConnection Type:Â Male National Pipe Thread (MNPT)Contact Rating Current [Max]:Â 250Current Consumption:Â Max. 45 mA for versions without 4-20 mA output signalMax. 70 mA for versions with 4-20 mA output signalTotal consumption max. 600 mA including switching currentDegree of Protection:Â Ingress Protection (IP65) and Ingress Protection (IP67) per International Electrotechnical Commission (IEC) 60529Digital Indicators:Â NOSHOK Digital Indicators provide local indication for pressure, level and temperature transmitters.Direct Current (DC) Voltage:Â 15 to 35Display:Â 14 segment-LED, red 4-digit, height 0.35"Distribution Manifolds:Â NOSHOK`s Distribution Manifolds connect multiple instruments to one diaphragm seal, eliminating multiple connections that lead to possible leak paths.Electrical Connection:Â M12 x 1 (4-pin)Electrical Protection:Â Protected against reverse polarity, over-voltage and short circuitHousing material:Â 304 Stainless SteelHysteresis:Â Fully AdjustableIndustry Standards/Certifications:Â European Conformity (CE) Compliant to Electromagnetic Compatibility (EMC) Norm European Standards (EN) 61326:2014/A1:1998, Request for Information (RFI), Electromagnetic Interference (EMI) and Electrostatic Discharge (ESD) ProtectionMeasuring Element:Â >150 psi: 316L Stainless steel>= 150 psi: 316L, PH grade Stainless steelMedia Temperature Range:Â -20 to 80Non-Repeatability:Â > 0.1% of span (IEC 61298-2)Operating Temperature [Max]:Â 70Operating Temperature [Min]:Â -20Options and Accessories:Â Stainless Steel Threaded Orifice (ST8)Single Factory Adjusted Switch Point (Specify)Double Factory Adjusted Switch Point (Specify)Output Signal:Â 4 mA to 20 mA or 0 Vdc to 10 Vdc; programmable and freely adjustableProcess Connection Size:Â 1/4Proof Pressure:Â 2 Times Full ScaleRelated Items:Â 102-MFS, 100 Series 10,000 psi Pressure Rating Mini Needle Valve with Hard Seat|602-MFS, 600 Series 1/4 in. Connection Size Block and Bleed Needle Valve with Hard SeatResponse Time:Â <= 5SchemaID:Â 105020Series:Â 800Service Life:Â 10,000,000 load cyclesShock According to International Electrotechnical Commission (IEC) 60068:Â > 50Switch Adjustable Range:Â 0 to 3,000Switch Parameter:Â Individually adjustable via external control keysSwitch Point:Â 0.25 to 100% of full scaleSwitching Function:Â 1 Normally Open (N.O.) or Normally Closed (N.C.) (Positive-Negative-Positive (P-N-P) or Negative-Positive-Negative (N-P-N)) with 0 Vdc to 10 Vdc 3-wire outputSwitching Number:Â 1|2Syndication:Â 1Type:Â Electronic Indicating Pressure SwitchUnit:Â 1Vibration According to International Electrotechnical Commission (IEC) 60068-2-6:Â > 20
SunSource Distribution Division: SunSource
Price:Â
$710.90
